Manual operated hand-valve, angle seat design, st. steel construction PN40
Standard type
Hand valve in angle seat design, for fluid and steam applications up to +200°C. (For example water, steam,
mineral-,heating- and hydraulic oil as well as fuel).
Max. working pressure= 25 bar.
Technical specifications:
Body material - 1.4408 (AISI 316L) and bonnet material st. steel 1.4571 (AISI 316Ti), stuffing box material -
PTFE (Teflon). PA - plastic hand wheel.
Body can be supplied threaded or with weld ends (our option -AS).
Seal: PTFE (Teflon)
DB-13-GSR-MK-ML
